C9500-16X-E Enterprise Managed Switch C9500 16 Port 10Gig

Brand Name : N/A

Model Number : C9500-16X-E Enterprise Managed Switch

Certification : N/A

Place of Origin : China

MOQ : 1 pcs

Price : $7700---8000 Negotiable

Payment Terms : Western Union T/T Bank Wire

Supply Ability : 25 PCS 130 DAYS

Delivery Time : 2---3 Working days

Packaging Details : add protecting boxes outside original box

Products Name : C9500-16X-E Enterprise Managed Switch C9500 16-port 10Gig switch Essentials

Weight : 15.01 KGS

Part Number : C9500-16X-E Enterprise Managed Switch

Color : Grey

Keywords : C9500-16X-E Enterprise Managed Switch C9500 16-port

Shipping : DHL UPS Fedex Aramex EMS

Contact Now

C9500-16X-E Enterprise Managed Switch C9500 16-port 10Gig switch Essentials

Products Overview

C9500-16X-E Overview C9500-16X-E Enterprise Managed Switch
C9500-16X-E is a C9500 16-port 10G switch, NW Ess. License. The C9500 Series Switches are the next
generation of enterprise-class core and aggregation layer switches, supporting full programmability and serviceability. Based on
an x86 CPU, the Catalyst 9500 Series is lead purpose-built fixed core and aggregation enterprise switching platform, built
for security, IoT, and cloud. The Catalyst 9500 Series is the industry's first purpose-built 40 Gigabit Ethernet line of switches
targeted for the enterprise campus. C9500-16X-E Enterprise Managed Switch C9500 16-port 10Gig switch Essentials.

Specification

C9500-16X-E Enterprise Managed Switch C9500 16-port 10Gig switch Essentials
Switching capacity Up to 240 Gbps
Forwarding rate Up to 360 Mpps
Total number of MAC addresses Up to 64,000
Total number of IPv4 routes (Address Resolution Protocol [ARP] plus learned routes)

Up to 64,000 indirect

Up to 80,000 host

C9500-16X-E Enterprise Managed Switch
Total number of IPv6 routes

Up to 32,000 indirect

Up to 40,000 host
QoS ACL scale Up to 18000
Security ACL scale Up to 18000
FNF entries Up to 512,000
DRAM 16 GB C9500-16X-E Enterprise Managed Switch
Flash 16 GB
VLAN IDs 4000
Total Switched Virtual Interfaces (SVIs) 4000
Jumbo frame 9198 bytes
Power supply specifications
Power Supply Selection PWR-C4-950WAC-R or PWR-C4-950WDC-R
Power max rating 950W C9500-16X-E Enterprise Managed Switch
Dimensions, physical specifications, weight, and MTBF
Dimensions (H x W x D) 1.73 x 17.5 x 21.52 in
Rack units (RU) 1RU C9500-16X-E Enterprise Managed Switch
Chassis with 2 power supplies and built-In fan 23.6 lb (10.7 kg)
Input voltage 90 to 264 VAC
Operating temperature 32° to 104°F (0° to 40°C)
Storage temperature -4° to 149°F (-20° to 65°C)
Relative humidity operating and nonoperating noncondensing

Ambient (noncondensing) operating: 5% to 90%

Ambient (noncondensing) nonoperating and storage: 5% to 95%
Altitude Operation up to 6000 feet at 55°C and 13,000 feet at 45°C
MTBF (hours) 315,790

C9500-16X-E Enterprise Managed Switch C9500 16 Port 10GigC9500-16X-E Enterprise Managed Switch C9500 16 Port 10Gig
